Lowrance Eagle 9 with TripleShot HD Transducer Chartplotter Fishfinder

000-16127-001

New

Lowrance Eagle 9 with TripleShot HD Transducer Chartplotter Fishfinder

Eagle® was born to make fishing as simple and enjoyable as possible.

Easy to use and quick to install with the NEW Tripleshot SplitShot™ HD Side Scan Transducer with FishReveal CHIRP / DSI & autotuning for optimal set up.

The IPS screen provides higher resolution and visibility from all angles.

With worldwide basemap chart

More details

R16,273.25

-15%

R19,145.00

More info

Lowrance Eagle 9 with TripleShot HD Transducer Chartplotter Fishfinder

Eagle® was born to make fishing as simple and enjoyable as possible. Easy to use and quick to install, this model features newly designed TripleShot™ HD Transducer with
FishReveal technology and autotuning for a quick and optimal set up. A new IPS screen provides higher resolution and visibility from all angles. This model comes
pre-loaded with a worldwide basemap chart.

Three technologies, one transducer

Give yourself the best chance of finding fish with underwater views to the side and below the boat, all in one transducer. TripleShot HD Transducer features the fish-finding

capability of wide-angle high CHIRP sonar and the high-resolution images of fish-holding structure from SideScan and DownScan Imaging™ for complete visibility to the

side and below you boat.


Unlock FishReveal™


Take the guesswork out of fish identification with FishReveal, combining DownScan with CHIRP for unparalleled target separation and identification.

Exclusive to Lowrance Eagle®

TripleShot HD Transducer is exclusive to Lowrance Eagle, our most accessible and easy to use fishfinder yet.

Key Features

Unlock wide-angle CHIRP sonar
Includes DownScan and SideScan Imaging
Featuring FishReveal
See beneath and to the sides of your boat

3 YEAR LOWRANCE SA WARRANTY

Specifications

Specifications

Display
Backlight ColorPure white LED
Display Resolution1024 x 600
Display Size9 inches
Screen Brightness1000 NITS
Viewing Angles80° top/bottom, 80° left/right
Connectivity
SD Card Storage1 slot (microSD® 32 GB maximum)
Cartography
Charts supportedC-MAP® DISCOVER™.
Electrical
Power Consumption max640 mA @ 12 V DC with backlight on full
Power Consumption typical640 mA @ 12 V DC with backlight on full
Recommended Fuse Rating3A
Supply Voltage12v DC (10.8-17VDC)
Environment
Humidity60°C, 95% relative humidity (RH) for 48 hours
Operating Temperature Range5°F to 131°F (-15°C to 55°C )
Storage Temperature Range4°F to 140°F (-20°C to 60°C )
WaterproofratingIPX7 with card door closed
GPS
CorrectionSBAS
Time to First Fix45s
MFD
Cartography includedC-MAP® Discover OnBoard™ charts for the US and Canada
Waypoints, Routes, Tracks3000 Waypoints 100 Routes 100 Trails
Physical
Compass Safe12" (300mm)
Dimensions W x H x D287.2 mm (11.30") x 162.5 mm (6.39") x 90 (3.54)
Mounting TypeGimbal bracket or dash mount
Weight0.9 kg (1.98 lb)
Other
InterfaceKeypad:8-way directional keypad, Zoom +/- (MOB), Exit, Enter, Menu, Waypoint, Power / backlight
Warranty Period 3 Year Lowrance SA Limited Warranty

In The Box

  • Eagle 9 Display
  • Lowrance Eagle  Tripleshot HD Skimmer Transducer with Mounting Hardware
  • Power Cable, with fuse and connectors
  • Eagle 9 Gimbal Bracket with Knobs

EAGLE TripleShot™ Transducer

SKU: 000-16285-001

With CHIRP, SideScan and DownScan Imaging™, the newly designed TripleShot™ HD Transducer offers improved clarity, depth, and sensitivity – all leading to better performance under the surface. And, with its distinctive arches, DownScan FishReveal™ makes it easier than ever before to tell the fish from the weeds.

Key Features

Unlock wide-angle CHIRP sonar

Includes DownScan and SideScan Imaging

Featuring FishReveal

See beneath and to the sides of your boat
