Garmin GPSMAP 1022xsv - Without Transducer

010-01740-02

New

Garmin GPSMAP 1022xsv - Without Transducer

Includes Wordwide Base Map and Single Channel Sonar Module

  • GPSMAP 1022xsv chartplotter
  • Power/data cable
  • NMEA 2000 T-connector
  • NMEA 2000 drop cable (2 m)
  • 8-pin transducer to 12-pin sounder adapter cable
  • Bail mount kit with knobs
  • Flush mount kit with gasket
  • Protective cover
  • Trim piece snap covers
  • Documentation

More details

Two Days from Order Required before Shipping

R41,579.10

-10%

R46,199.00

More info

Garmin GPSMAP 1022xsv - Without Transducer

GPSMAP 1022 is designed for cruisers, sailors and sailing racers who need the advanced all-in-one solution provided by our 10-inch keyed chartplotter.

10-inch Chartplotter/Sonar Combo Is An All-in-One Solution

  • 10-inch colour display (Non Touch) with keypad interface and multifunction control knob
  • High-sensitivity internal 10 Hz GPS and GLONASS receiver
  • Built-in single channel CHIRP sonar, CHIRP ClearVü and CHIRP SideVü scanning sonar and Panoptix™ support (transducers sold separately)
  • Fully network capable for Garmin Marine Network and NMEA 2000® plus NMEA 0183 support
  • Supports optional BlueChart® g2 Vision® HD charts for Auto Guidance and other premium navigation features

CLICK HERE TO DOWNLOAD GARMIN MARINE PRODUCT COmPARISON CHART

CLICK HERE TO DOWNLOAD GARMIN TRANSDUCER SELECTION GUIDE

Includes Wordwide Base Map and Single Channel Sonar Module

  • GPSMAP 1022xsv chartplotter / fishfinder (No Transducer)
  • Power/data cable
  • NMEA 2000 T-connector
  • NMEA 2000 drop cable (2 m)
  • 8-pin transducer to 12-pin sounder adapter cable
  • Bail mount kit with knobs
  • Flush mount kit with gasket
  • Protective cover
  • Trim piece snap covers
  • Documentation

Experience an advanced all-in-one solution with our 10-inch GPSMAP 1022xsv keyed combo. Comes preloaded with

support for Garmin CHIRP sonar, CHIRP ClearVü and CHIRP SideVü.

It also has built-in support for Panoptix all-seeing sonar and premium Garmin sonar modules (transducers sold separately).

Features a large, bright screen coupled with a quick and easy-to-use keypad interface with user-programmable keys and a multifunction control knob.

The Ultimate Connected Boating App

The free all-in-one ActiveCaptain™ app allows you to manage your marine experience from nearly anywhere. It creates a simple

yet powerful connection between your compatible mobile device and your Garmin chartplotter, charts, maps and the boating community.

Wherever you are, you’ll have unlimited access to your cartography, the ability to purchase new maps and charts and access to the Garmin

Quickdraw™ Contours Community. Stay connected with smart notifications on your chartplotter screen. You can also plan a trip or pre-fish

a lake, and ActiveCaptain will automatically sync with your chartplotter. Even get notifications for software updates, and decide when to

download them on your device.

¹Auto Guidance is for planning purposes only and does not replace safe navigation operations.

iPhone and iPad are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc.

Wi-Fi is a registered trademark of the Wi-Fi Alliance.

General
PHYSICAL DIMENSIONS 318 x 185 x 69 cm
DISPLAY SIZE

22.4 x 12.5 cm; 10.1 inch (25.7 cm) diagonal
DISPLAY RESOLUTION 1024 x 600 pixels
DISPLAY TYPE WSVGA display
TOUCH SCREEN

No
WEIGHT

1.85 kg
WATER RATING IPX7
MOUNTING OPTIONS Bail or flush

Maps & memory
CARD SLOTS 2 SD™ cards
WAYPOINTS 5,000
ROUTES 100

Sensors
BUILT-IN RECEIVER HZ 10 Hz high-sensitivity
NMEA 2000® COMPATIBLE Yes
NMEA 0183 COMPATIBLE Yes

Chartplotter features
GARMIN SMARTMODE COMPATIBLE (CUSTOMISABLE MONITOR PRESETS) Yes
SUPPORTS AIS (TRACKS TARGET SHIPS POSITION) Yes
SUPPORTS DSC (DISPLAYS POSITION DATA FROM DSC-CAPABLE VHF RADIO) Yes
SUPPORTS FUSION-LINK™ COMPATIBLE RADIOS Yes
GSD™ BLACK BOX SONAR SUPPORT Yes
GCV™ BLACK BOX SONAR SUPPORT Yes
ACTIVECAPTAIN COMPATIBLE Yes
GRID™ (GARMIN REMOTE INPUT DEVICE) COMPATIBLE Yes
WIRELESS REMOTE COMPATIBLE Yes

Connections
NMEA 0183 INPUT (RX) PORTS

1
VIDEO INPUT PORTS

1 BNC
VIDEO OUTPUT PORTS None
GARMIN MARINE NETWORK™ PORTS

2

Sonar features & specifications
DUAL-FREQUENCY (50/200 KHZ) SONAR CAPABLE Yes
DUAL-BEAM (77/200 KHZ) SONAR CAPABLE Yes
CLEARVÜ

Yes with CHIRP (built-in)
MAXIMUM DEPTH 1500m at 1kW (depth capacity is dependent on water bottom type and other water conditions)
BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) Yes
WATER TEMPERATURE LOG AND GRAPH Yes
SONAR RECORDING Yes
SONAR HISTORY REWIND  Yes

COMPATABILITY LIST

  • Compact Reactor™ 40 Hydraulic Autopilot Starter Pack
  • Compact Reactor™ 40 Hydraulic Autopilot with GHC™ 20 and Shadow Drive™ Pack
  • Compact Reactor™ 40 Hydraulic Autopilot with GHC™ 20 Corepack
  • Garmin AIS™ 300 Blackbox Receiver
  • GLS™ 10 Sonar Module
  • GMR™ 1224 xHD2
  • GMR™ 1226 xHD2GR™ 18 HD+
  • GMR™ 18 HD
  • GMR™ 18 xHD
  • GMR™ 24 HD RadoGMR™ 24 xHD
  • GMR™ 2524 xHD2
  • GMR™ 2526 xHD2GMR™ 424 xHD2
  • GMR™ 606 xHD Open Array Radar and Pedestal
  • GMR™ 624 xHD2GMR™ 626 xHD2
  • GMR Fantom™ 124
  • GMR Fantom™ 126
  • GMR Fantom™ 18
  • GMR Fantom™ 24
  • GMR Fantom 254
  • GMR Fantom 256
  • GMR Fantom™ 4
  • GMR Fantom™ 54
  • GMR Fantom™ 56
  • GMR Fantom™ 6
  • GSD™ 24 Advanced Sonar Module
  • GSD™ 25 Premium Sonar Module
  • GSD™ 26 CHIRP Professional Sonar Module
  • Meteor™ 300 Audio System
  • OnDeck™ Hub
  • Panoptix LiveScope™ System
  • Panoptix™ PS22-TR
  • Panoptix™ PS30
  • Panoptix™ PS31Panoptix™ PS51-TH
  • Panoptix™ PS60 Thru-hull Down Transducer
  • Reactor™ 40 Hydraulic Autopilot
  • Reactor™ 40 Hydraulic Corepack with SmartPump
  • Reactor™ 40 Mechanical/Retrofit/Solenoid Corepack
  • Reactor™ 40 Mechanical/Retrofit/Solenoid Corepack
  • Reactor™ 40 Steer-by-wire Corepack for Volvo-Penta®Reactor™ 40 Steer-by-wire Corepack for Yamaha® Helm Master™
  • Reactor™ 40 Steer-by-wire Standard Corepack
  • VHF 100 Marine Radio
  • VIRB® 360
  • Garmin Force Trolling Motor
