Garmin ECHOMAP UHD2 52cv Chartplotter / Fishfinder No Transducer
R9,899.00
R8,444.00
Tax included
Garmin ECHOMAP UHD2 52cv 5" Chartplotter / Fishfinder No Transducer
WHY TALK TO A LOCAL WHEN YOU CAN FISH LIKE ONE?
They say locals know best. But anyone who says that hasn’t fished with the ECHOMAP UHD2 5”and 7” chartplotters with clear, crisp sonar and mapping.
- ECHOMAP UHD2 52 cv
- Power/data cable
- Tilt mount
- Flush mount
- Hardware
- Documentation
Garmin ECHOMAP UHD2 52cv 5" Chartplotter / Fishfinder No Transducer
They say locals know best. But anyone who says that hasn’t fished with the ECHOMAP UHD2 5”and 7” chartplotters with clear, crisp sonar and mapping.
In the Box:
- ECHOMAP UHD2 52 cv
- Power/data cable
- Tilt mount
- Flush mount
- Hardware
- Documentation
Features
The bright 5” or 7” keyed display is made for convenience.
Get double the views1 with Garmin CHIRP traditional and ClearVü scanning sonars.
What’s under the water looks even better with high-contrast vivid color palettes.
Wi-Fi® connectivity2 between compatible chartplotters makes it easy to share info.
Enjoy No. 1 in mapping3 with our LakeVü g3 and BlueChart® maps with Navionics® data.
Know the waters, catch more fish.
SONAR SUPPORT
With crisp, clear traditional sonar and brilliant ClearVü sonar, the fish will have nowhere to hide.
VIVID COLOR PALETTES
High-contrast vivid scanning sonar color palettes make it easier than ever to distinguish targets and structure.
BUNDLE YOUR TRANSDUCER
Your ECHOMAP UHD2 device supports a variety of Garmin transducers for two types of sonar: Garmin traditional and ClearVü scanning sonars.
PRELOADED CHARTS
Know the waters you’re in as if you grew up fishing them by using built-in LakeVü g3 inland maps, BlueChart g3 coastal charts or worldwide basemap with support for Garmin Navionics+™ and Garmin Navionics Vision+™ marine cartography.
WIRELESS NETWORKING
If you have another compatible ECHOMAP UHD2 chartplotter on your boat, the 5” and 7” models can wirelessly share information — such as sonar, waypoints and routes — with them.
ACTIVECAPTAIN® APP
Built-in Wi-Fi connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications, software updates, Garmin Quickdraw™ Community data and more2.
Manage your marine experience using the free ActiveCaptain app
General |
|
| DIMENSION | 7.4" x 4.8" x 2.4" (18.8 x 12.2 x 6.2 cm) |
|---|---|
| INPUT | |
| DISPLAY SIZE | 4.3" x 2.6" (10.9 x 6.6 cm) |
| DISPLAY RESOLUTION | 800 x 480 pixels |
| DISPLAY TYPE | WVGA, IPS |
| WEIGHT |
1.1 lbs (0.5 kg) |
| WATERPROOF |
IPX7 |
| MOUNTING OPTIONS | Bail or flush |
Maps & Memory |
|
| ACCEPTS DATA CARDS |
1 microSD™ card; 32 GB maximum size |
|---|---|
| WAYPOINTS |
5,000 |
| TRACK POINTS | 50,000 |
| TRACKS | 50 saved tracks |
| NAVIGATION ROUTES | 100 |
Sensors |
|
| HAS BUILT-IN RECEIVER | Yes |
|---|---|
| RECEIVER |
5 Hz |
| GPS | Yes |
| SUPPORTS WAAS | Yes |
Built-in Maps |
|
| BLUECHART (COASTAL) | yes (see Additional) |
|---|---|
| LAKEVU (INLAND) | yes (see Additional) |
| (SOUNDER) TIDE TABLES | yes (see Additional) |
Optional Map Support |
|
| BLUECHART G3 | Yes |
|---|---|
| BLUECHART G3 VISION | Yes |
| LAKEVÜ G3 | Yes |
| LAKEVÜ G3 ULTRA | Yes |
| GARMIN NAVIONICS+™ | Yes |
| GARMIN NAVIONICS VISION+™ | Yes |
| (SOUNDER) TOPO | Yes |
| STANDARD MAPPING | Yes |
| GARMIN QUICKDRAW CONTOURS | Yes |
Chartplotter Features |
|
| ACTIVECAPTAIN® COMPATIBLE | Yes |
|---|---|
Sonar Features & Specifications |
|
| DISPLAYS SONAR | Yes (With Optional Transducer) |
|---|---|
| POWER OUTPUT | 500 W |
| TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) | built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP) |
| CLEARVÜ | built-in 260/455/800/1000/1200 kHz |
Connections |
|
| 4-PIN TRANSDUCER PORTS | 1 |
|---|---|
| GARMIN WI-FI NETWORK (LOCAL CONNECTION) | Yes |
Electrical Features |
|
| POWER INPUT | 9 to 18 Vdc |
|---|---|
| TYPICAL CURRENT DRAW AT 12 VDC | 1.0 A |
| MAXIMUM CURRENT DRAW AT 12 VDC | 1.5 A |
| MAXIMUM POWER USAGE AT 10 VDC | 18W |
Additional |
|
| ADDITIONAL |
|
|---|---|
