Garmin GT54UHD-TM 350W Trad HW-CHIRP CV:800 SV 455/800/1200 12-pin Ultra High-Definition Scanning Sonar All-in-one Transducer
Recipient :
* Required fields
or Cancel
The GT54 ultra high-definition all-in-one transducer provides image details so clear and precise, you can actually see fish hanging just off branches of submerged trees, brush and rocks. You can see size differences between bigger and smaller fish and even see individual fish swimming in bait balls. You get the highest resolution ClearVü and SideVü scanning sonar images available plus amazingly clear high wide CHIRP traditional sonar — all in one transducer.
Ultra high-definition scanning sonar provides extended range and depth performance. It shows you incredibly detailed images of fish and structure up to 60 m (200 ft) below your boat with 800 kHz ClearVü, while two SideVü sonar frequency settings (455/1200 kHz) provide options for extended range of up to 152.4 m (500 ft). It's easy to install with included transom and trolling motor mounts so you can start fishing faster.
Transducer cable length | 20 ft. | ||||||||||||||||
Transducer power | CHIRP Traditional 350 W; ClearVü/SideVü 350 W | ||||||||||||||||
Transducer frequency | CHIRP High Wide (150-240 kHz); UHD ClearVü CHIRP 800 kHz (760-880 kHz); UHD SideVü 1,200kHz (1020-1230 kHz); CHIRP SideVü 455 kHz (425-485 kHz) | ||||||||||||||||
Transducer maximum depth | CHIRP: 800 ft.; ClearVü 200 ft.; SideVü 500'; UHD SideVü 125' | ||||||||||||||||
Transducer number of pins | 12 | ||||||||||||||||
Transducer beamwidth | CHIRP: 24°-16° ClearVü: 0.94°x60° @ 800 kHz SideVü: 1.62°x50° UHD SideVü: 0.441°x52° @ 1200 kHz |
||||||||||||||||
Misc |
|
||||||||||||||||
Transducer depth/speed/temperature | Depth and Temperature | ||||||||||||||||
Transducer supported deadrise/transom angles | 0°-70° degree transom |
